Order number: LG51184
Prices are only visible after login.
Availability: Ready to ship today, Delivery time appr. 1-3 workdays
LED Power Supply The Mean Well NPF-60D-12 is an extremely versatile power supply... more
Product information "Mean Well NPF 60D-12"
LED Power Supply
The Mean Well NPF-60D-12 is an extremely versatile power supply for all kinds of passive LED projectors and strips. You can use it in outdoor installations such as gardens and wellness areas.
- usable for all DC 12V single-colour LED strips and LED bulbs
- Mains input: AC 90 - 305V, 47 - 63Hz
- Housing: Plastic
- Output voltage: DC 7,2 - 12V, constant current
- Rated power: 5A
- Output power: 60W
- Dimmable: yes (1-10V)
- Protection: short circuit, over load, over voltage
- Scope: LED strips and Illumination
- IP class: IP67 for indoor and outdoor use without direct sunlight exposure. Please avoid immerse in the water over 30 minutes
- Safety standars: F, SELV, TÜV, CE, ENEC
- Power Faktor: >0,95
- Efficiency: 86%
- Ambient temperature: -20° to 80°C
- Warranty: 5 years
Dimensions: 150 x 53 x 35 mm
Related links to "Mean Well NPF 60D-12"
|Method of Dimming:||1-10V|
|Input Current:||AC 90 - 305V, 400mA, 47/63Hz, DC 127 - 431V|
|Power Consumption:||60 W|
|Power Factor (PF):||>0.95|
|Input Driver:||cable with flying leads|
|Output of Driver:||DC 12V, 5000mA|
|Electrical Protection Class:||II|
|Compatible with Emergency Current:|
|Ambient Temperature (TA):||-40°C - 80°C|
|Special Feature of Housing:||fully encapsulated|
|Net Weight:||700 g|
|Weight incl. Packaging:||0.7 kg|
|Operating Hours:||>50.000 h|
|Customs Tariff Number:||8504 40 90|
