EGETA 1500 150-840-22500LM Flood DIN 18032-3 UGR<22 DALI 2.0 Dim
Order number: LG32182DA
Available soon
Prices are only visible after login.
Availability: Only on Request. Estimated delivery time more than 8 weeks.
Dimensions
- Order number: : LG32182DA
- Luminous Flux: 22500 lm
- Power Draw: Power Select (60, 80, 100, 150 W)
- Light Color: neutralwhite (4000 K)
- Input Current: AC 200-240V, 50/60Hz, DC 186-250V
- Color Rendering Index (CRI): ≥80 Ra
- IP Code: 20
- Beam Angle: 80°
- LED-Chip: Jufei 205lm/W SMD2835
- Housing Color: white
- Dimensions: 1500x350x60 mm
- Warranty: 5 years
Indoor Sporthall luminaire Extremly robust Indoor Sporthall light... more
Product information "EGETA 1500 150-840-22500LM Flood DIN 18032-3 UGR<22 DALI 2.0 Dim"
Indoor Sporthall luminaire
- Extremly robust Indoor Sporthall light IK10 ball impact resistance DIN 18032-3.
- Elegant white steel housing with prismatic diffusor
- Dali 2.0 or push dimming with power select option
- Easy installtion directly on surfaces with screws. Can be suspended or fixed on ceilings see optional accessories
- Through wireing: 5 x 2,5mm²
- Low glare UGR <22 (100W - 150W) perfect for many kind of indoor sports
- High efficency: max. 150lm/W
- ball throw protected
Applications:
Sporthall: Hockey, Volleyball, Basketball, Gym, Football, Cricket, Tennis
Related links to "EGETA 1500 150-840-22500LM Flood DIN 18032-3 UGR<22 DALI 2.0 Dim"
Technical Details:
| Luminous Flux: | 22500 lm |
| Light Yield: | 150 lm/W |
| Light Temperature: | 4000 K |
| Light Color: | neutralwhite |
| Color Rendering Index: | ≥80 Ra |
| Color Consistency (SDCM): | <3 |
| Beam Angle: | 80 ° |
| Unified Glare Rating (UGR): | 22 |
| Light Emission: | downward |
| Dimmable: |  |
| Method of Dimming: | DALI,Push-Dim,"Power Select" |
| LED-Chip Manufacturer: | Jufei 205lm/W |
| LED-Chip: | SMD2835 |
| Number of LED: | 840 |
| Ignition Time: | <0,5 s |
| Glow Wire Test 650°C/30s | |
| Input Current: | AC 200-240V, 50/60Hz, DC 186-250V |
| Power Consumption: | Power Select (60, 80, 100, 150 W) |
| Contains Driver: | |
| Driver Manufacturer: | Boke |
| Power Factor (PF): | >0.9 |
| Input Driver: | terminal |
| Output of Driver: | DC 100-300V, 200-700mA |
| CC/CV: | CC |
| Output Current Adjustable: | |
| Input Lamp: | Terminal |
| Switching Cycles: | >200.000 |
| Electrical Protection Class: | I |
| Compatible with Emergency Current: | |
| Ambient Temperature (TA): | -20°C - 40°C |
| Storage Temperature: | -20°C - 60°C |
| Dimensions: | 1500x350x60 mm |
| Mounting: | Decke,Deckenabhängung |
| Montageart: | surface mounted |
| IP Class: | 20 |
| IK Code: | 10 |
| Housing Color | white |
| Housing Material: | steel |
| Special Feature of Housing: | Ballwurfsicher DIN18032-3 |
| Cover: | prismatic |
| Net Weight: | 11200 g |
| Type of Packaging: | box |
| Weight incl. Packaging: | 14.7 kg |
| Content Master Package: | 1 |
| Dimensions of Master Package: | 1700x428x150 mm |
| Weight Master Package: | 14,7 kg |
| Product Line: | Premio Line |
| Warranty | 5 years |
| Operating Hours: | >100.000 h L80/B10 |
| Disposal Obligation: | |
| Customs Tariff Number: | 9405429000 |
| Certifications | CE,LM80,D |
| Barcode: | 4250557826684 |
| Einfache, und schnelle Montage, In/Out | |
| Dali 2.0 Push-Dim 1-100% Power Select | |
| Ballwurfsicher nach DIN 18032-3 | |
| Ball impact resistance DIN 18032-3 | |
| Low glare UGR<22, IP20 IK10, RG0 | |
