Order number: LG5397

Prices are only visible after login.

Last Stock

Availability: low stock

X Product information sheet (PDF)

Product information sheet

LED Flexstrip Catena Eco The Litegear® Catena Eco is a... more

Close menu

Product information "Catena FlexStrip Eco 30R"

LED Flexstrip

Catena Eco

The Litegear® Catena Eco is a flexible execution of well-known LED strips. Because of the flexible board even the fixture on round surfaces is no problem. By the low power consumption and the high life it concerns a "Green Energy technology" product. For long lifespan mount the strip on a aluminum rail or strip.

The objects can be injected on two sides. Suitable LED driver with achievements between 10W and 300W are in our assortment. The LED driver can be steered manually or with DMX. We offer Litegear® Catena Eco in different achievements and colours, as well as white or RGB (Multicolor). Catena Eco is suited very well for back-lits, translucent surfaces or for indirect illumination of objects. LED strips will revolutionize the thinking of architecture light and will create a multiplicity of new areas of application.

Features:

SMD LED Flexible Strip is totally and genuinely flexible strip light. It can be used as edge-lighting of transparent or diffused materials, illuminated signs and path/contour marking.
SMD Flex makes it possible to use LED lighting in places that could not be reached before. Curves, cone and round objects can now be furnished with LED lighting.
3M stick at the back of the strip, easy to install and more brightness than the 30led per mater
CO² reduction
long lifetime

Scope:

for indoor decoration, Bar, KTV, Hotel, stage
Backlight or edge lighting for signage
Path and contour marking
Marine light, Task lighting
replacement of fluorescent light
decorative lights for holiday, event, show, exhibition
Architectural lights for canopy, corridor, window, archway
DIY lights for home use

Related links to "Catena FlexStrip Eco 30R"

Zurück

Technical Details:

Luminous Flux per Meter:	480 lm
Output per Meter:	9 W
Light Yield:	53 lm/W
Light Temperature:	6500 K
Light Color:	cold white
Beam Angle:	120 °
LED-Chip:	SMD 5050
LED per Meter:	30
Cut After:	165 mm

Output of Driver:	DC 24V
Input Lamp:	cable with flying leads
Ambient Temperature (TA):	-20°C - 45°C

Dimensions:	5000x10x2 mm
IP Class:	20
Net Weight:	125 g

Type of Packaging:	bag
Weight incl. Packaging:	0.2 kg

Warranty	2 years
Operating Hours:	>30.000 h L70/B50
Disposal Obligation:
Customs Tariff Number:	8539510000
Certifications	CE
Barcode:	4250557802442

Technical Data Sheet (PDF)
