Catena FLEX Wallwasher Strip 400cm
Order number: LG54196
Prices are only visible after login.
Availability: Only on Request. Estimated delivery time more than 8 weeks.
Product information sheet
- Order number: : LG54196
- Luminous Flux: 10080 lm
- Power Draw: 96 W
- Light Color: neutralwhite (4000 K)
- Input Current: DC 24V, 62,5 (3LEDS)mA
- Color Rendering Index (CRI): ≥85 Ra
- IP Code: 65
- Beam Angle: 45x25°
- LED-Chip: Philips Lumileds High-Power
- Housing Color: transparent milchig
- Dimensions: 4000x20x10,5 mm
- Warranty: 2 years
Biegbarer LED-Strip mit Linsenoptik und gerichtetem Licht Wetterfester spezieller... more
Product information "Catena FLEX Wallwasher Strip 400cm"
Biegbarer LED-Strip mit Linsenoptik und gerichtetem Licht
Wetterfester spezieller LED Strip zur Ausleuchtung von Wänden und Fassaden. UV-beständiges Material mit hoher Transparenz. 95% und hoher Temperaturbeständigkeit bis - 25°C bis + 50°C.
Schwer entflammbar V2!
Lieferbar mit unterschiedlichen Linse und Abstrahlwinkeln: 15°, 25°, 45°, 60°, 20x45°, 20x45° um 10° nach vorne gerichtet
Maximale Länge pro Einspeisung: 10m, max. 5m pro Rolle
Zuleitung 2m
Es wird ein optionales Netzteil benötigt: 24V DC
Alle 62,5mm schneidbar, (nach 3 LEDs)
Related links to "Catena FLEX Wallwasher Strip 400cm"
Technical Details:
| Luminous Flux per Meter: | 2500 lm |
| Output per Meter: | 24 W |
| Luminous Flux: | 10080 lm |
| LED Output: | 96 W |
| Light Yield: | 104 lm/W |
| Light Temperature: | 4000 K |
| Light Color: | neutralwhite |
| Color Rendering Index: | ≥85 Ra |
| Color Consistency (SDCM): | <3 |
| Beam Angle: | 45x25 ° |
| Light Emission: | downward |
| Dimmable: |  |
| LED-Chip Manufacturer: | Philips Lumileds |
| LED-Chip: | High-Power |
| LED per Meter: | 48 |
| Cut After: | 62.5 mm |
| Number of LED: | 48 |
| Ignition Time: | <0,5 s |
| Input Current: | DC 24V, 62,5 (3LEDS)mA |
| Power Consumption: | 96 W |
| Output of Driver: | DC 24V |
| CC/CV: | CV |
| Input Lamp: | 4m Kabel |
| Input Strip: | cable with flying leads - one side |
| Ambient Temperature (TA): | -40°C - 45°C |
| Storage Temperature: | -40°C - 45°C |
| Dimensions: | 4000x20x10,5 mm |
| Mounting: | Decke |
| Montageart: | surface mounted |
| IP Class: | 65 |
| IK Code: | 08 |
| Housing Color | transparent milchig |
| Special Feature of Housing: | biegbar |
| Cover: | Lens |
| Type of Packaging: | bag |
| Dimensions of Packaging: | 420x12x10 |
| Content Master Package: | 8 |
| Product Line: | Advance Line |
| Warranty | 2 years |
| Operating Hours: | >40.000 h L80/B20 |
| Disposal Obligation: | |
| Customs Tariff Number: | 8539510000 |
| Certifications | CE |
| Barcode: | 4250557822389 |
| Anti UV | |
| 24V for external power supply | |
