Emergy Plane Mini 1,5-840-150lm SC WH Widebeam 155°

LG60026
Preise sind erst nach der Anmeldung sichtbar.

Availability: Ready to ship today, Delivery time appr. 1-3 workdays

Dimensions

Dimensions
  • LG60026
  • Luminous Flux: 150 lm
  • Power Draw: 2 W
  • Light Color: neutralwhite (4000 K)
  • Input Current: AC 220-240VV, 50/60Hz
  • Color Rendering Index (CRI): ≥80 Ra
  • IP Code: 20
  • Beam Angle: 155°
  • LED-Chip: Tiandian SMD 5050
  • Housing Color: white
  • Dimensions: 45x27 mm
  • Cut-Out Dimensions: 35 mm
  • Warranty: 5 years

Luminous Flux

150
lm

Power Draw

2 W

Light Color

4000 K
neutralwhite

Color Rendering Index (CRI)

CRI
>80 Ra

IP Code

IP 20

Beam Angle

155°

mounting type

Light Direction

Dimensions

(ØxH) in mm
45x27

Warranty

5 years

Mini LED escape route light   Safety light with single battery supply for escape... more
Product information "Emergy Plane Mini 1,5-840-150lm SC WH Widebeam 155°"
Mini LED escape route light

Safety light with single battery supply for escape route illumination. 3 hours of emergency lighting by means of lithium battery. 2500mA, 3.6V. Good brightness and wide light distribution.Manual function test via push button. LED light source with long life up to 50,000 hours. LED status display via red and green LED. Compact dimensions for integration in grid- and plasterboard ceilings. Two-part structure: round LED unit and separate battery and supply unit with switchover. Permanent phase monitoring. Elegant, inconspicuous ceiling installation.

  • Operating equipment: emergency / network: electronic ballast
  • auto test function
  • Beam angle: symmetrical 155 °
  • LED: 1,5W
  • Luminous flux: typ. 150 lumens
  • Installation dimensions see drawing
Related links to "Emergy Plane Mini 1,5-840-150lm SC WH Widebeam 155°"
Technical Details:

Luminous Flux: 150 lm
LED Output: 1.5 W
Light Yield: 100 lm/W
Light Temperature: 4000 K
Light Color: neutralwhite
Color Rendering Index: ≥80 Ra
Color Consistency (SDCM): <6
Beam Angle: 155 °
Light Emission: downward
LED-Chip Manufacturer: Tiandian
LED-Chip: SMD 5050
Number of LED: 1
Ignition Time: <1 s
Input Current: AC 220-240VV, 50/60Hz
Power Consumption: 2 W
Contains Driver: ja
Power Factor (PF): >0.5
Input Driver: terminal
CC/CV: CC
Input Lamp: terminal
Switching Cycles: >50.000
Electrical Protection Class: II
Ambient Temperature (TA): 0°C - 40°C
Storage Temperature: 0°C - 50°C
Dimensions: 45x27 mm
Installation Depth: 25 mm
Cut-Out Dimensions: 35 mm
Mounting: Decke
Montageart: recessed
IP Class: 20
IK Code: 06
Housing Color white
Housing Material: Polycarbonat
Special Feature of Housing: Luminaire IP54 room side
Cover: Lens
Net Weight: 160 g
Luminaire Type: Fluchtwegleuchtung
Testing Facility: automatischer Selbsttest
Battery Warranty: 3
Discharge Duration: ≥3 h
Battery Type: Li-Ion
Battery Current: 2500 mA
Battery Charge Duration: 8 h
Initial Charge Duration: 16 h
Charging Power Consumption: 4.5 W
Battery Cell Quantity 1
Luminous Flux in Battery Mode: 150 lm
Safety Standards: DIN EN 60598-2-22, DIN EN 62034: 2012, Anforderung nach DIN EN 50172
Certified By: LIA
Type of Packaging: box
Dimensions of Packaging: 242x95x30
Weight incl. Packaging: 0.22 kg
Content Master Package: 60
Dimensions of Master Package: 49,8x31,8x31,5 mm
Weight Master Package: 13,2 kg
Product Line: ECO Line
Warranty 5 years, 25.000 h
Operating Hours: >50.000 h L70/B20
Disposal Obligation: ja
Customs Tariff Number: 9405409990
Certifications CE,RoHS,TÜV,LM80,EMC,LVD,Reach,D
Barcode: 4250557819945
Über- und Entladeschutz, greene/rede Status LED
gewinkelter Treiber/angled driver
Selbstest: 30s/Woche, Dauertest: 1xyear
selftest: 30s/week, full duartion test: 1 x year
IR Empfänger für Fernbedienung
