Newtura Round 240-20-830/840-1700LM CCT select
Order number: LG58219
Prices are only visible after login.
Availability: Ready to ship today, Delivery time appr. 1-3 workdays
Dimensions
- Order number: : LG58219
- Luminous Flux: 1700 lm
- Power Draw: 20 W
- Light Color: CCT Select (3000,3500,4000 K)
- Input Current: AC 220 - 240V, 0,09mA, 50/60Hz
- Color Rendering Index (CRI): ≥82 Ra
- IP Code: 20 (54 room side)
- Beam Angle: 110°
- LED-Chip: Samsung SMD 2835
- Housing Color: white
- Dimensions: 240x35 mm
- Warranty: 5 years
Ceiling light with CCT select Newtura is a round surface-mounted luminaire... more
Product information "Newtura Round 240-20-830/840-1700LM CCT select"
Ceiling light with CCT select
Newtura is a round surface-mounted luminaire with an integrated LED driver. Via an integrated switch the installer can select 3 different light colors: 3000, 3500, 4000 Kelvin (warm white to natural white). Optionally also available as a dimmable version (Dali or 0-10V). Easy assembly thanks to separate mounting plate and twist lock with additional fall protection using a safety rope. Integrated electrical terminal block for power loop. Can also be suspended using a rope set. On request, the lamp can also be equipped with an internal microwave sensor or battery emergency light pack. As a dimmable variant with Meanwell® LC-45 driver, it is also suitable for operation on emergency power central battery systems in accordance with EN 60598-2-22. Due to the large internal space, emergency switch relais can also be integrated.
High quality Samsung LED chips for long life and high luminous flux maintenance. Elegant and high-quality die-cast aluminum housing. Universal mounting options.
Related links to "Newtura Round 240-20-830/840-1700LM CCT select"
Technical Details:
| Luminous Flux: | 1700 lm |
| LED Output: | 18 W |
| Light Yield: | 85 lm/W |
| Light Temperature: | 3000,3500,4000 K |
| Light Color: | CCT Select |
| Color Rendering Index: | ≥82 Ra |
| Color Consistency (SDCM): | <4 |
| Beam Angle: | 110 ° |
| Unified Glare Rating (UGR): | 22 |
| Light Emission: | downward |
| LED-Chip Manufacturer: | Samsung |
| LED-Chip: | SMD 2835 |
| Ignition Time: | <0,5 s |
| Input Current: | AC 220 - 240V, 0,09mA, 50/60Hz |
| Power Consumption: | 20 W |
| Contains Driver: |  |
| Power Factor (PF): | >0.95 |
| Input Driver: | terminal |
| Output of Driver: | DC 36V, 500mA |
| CC/CV: | CC |
| Input Lamp: | Terminal |
| Switching Cycles: | >100.000 |
| Electrical Protection Class: | II |
| Ambient Temperature (TA): | -20°C - 40°C |
| Storage Temperature: | -40°C - 55°C |
| Dimensions: | 240x35 mm |
| Mounting: | ceiling,wall |
| Montageart: | surface mounted |
| IP Class: | 20 (54 room side) |
| IK Code: | 08 |
| Housing Color | white |
| Housing Material: | aluminum |
| Coating: | powder-coated |
| Special Feature of Housing: | IP54 room side |
| Cover: | opal |
| Net Weight: | 1185 g |
| Type of Packaging: | box |
| Dimensions of Packaging: | 250X45X250 |
| Weight incl. Packaging: | 1.289 kg |
| Content Master Package: | 12 |
| Dimensions of Master Package: | 515x295x270 mm |
| Weight Master Package: | 16,06 kg |
| Product Line: | Premio Line |
| Warranty | 5 years |
| Operating Hours: | >50.000 h L80/B20 |
| Disposal Obligation: | |
| Customs Tariff Number: | 9405119090 |
| Certifications | CE,LM80,SELV,D |
| Barcode: | 4250557819495 |
| Lichtfarbe-/CCT-Select: 3000K, 3500K, 4000K | |
Runde LED-Wand-/Deckenanbauleuchte mit wählbarer Lichtfarbe in einem eleganten Design more
Runde LED-Wand-/Deckenanbauleuchte mit wählbarer Lichtfarbe in einem eleganten Design
Vorschaltgerät: LED-Treiber
Temperaturbereich: -20°C - 40°C
Lichtstrom: 1700 lm
LED-Leistung: 20 W
Leuchten-Lichtausbeute: 85 lm/W
Farbtemperatur: 3000,3500,4000 K
Lichtfarbe: CCT Select
Farbwiedergabeindex (Ra): >82
Farbtoleranz (SDCM): <4
Abstrahlwinkel: 110°
UGR: 22
Lichtaustritt: direkt
Maße: 240x35 mm
Montageart: Aufbau (Decke,Wand)
Schutzklasse (DIN EN 61140): I
Schutzart (DIN EN 60529): IP20 (IP54 raumseitig)
Stoßfestigkeitsgrad (IEC 62262): IK08
Außenfarbe: white
Gehäusematerial: Aluminium
Gehäusebeschichtung: pulverbeschichtet
Abdeckung: opal
Nettogewicht: 1185 g
Garantie: 5 Jahre
Mittlere Lebensdauer (L80/B20): 50000 h
Vorschaltgerät: LED-Treiber
Temperaturbereich: -20°C - 40°C
Lichtstrom: 1700 lm
LED-Leistung: 20 W
Leuchten-Lichtausbeute: 85 lm/W
Farbtemperatur: 3000,3500,4000 K
Lichtfarbe: CCT Select
Farbwiedergabeindex (Ra): >82
Farbtoleranz (SDCM): <4
Abstrahlwinkel: 110°
UGR: 22
Lichtaustritt: direkt
Maße: 240x35 mm
Montageart: Aufbau (Decke,Wand)
Schutzklasse (DIN EN 61140): I
Schutzart (DIN EN 60529): IP20 (IP54 raumseitig)
Stoßfestigkeitsgrad (IEC 62262): IK08
Außenfarbe: white
Gehäusematerial: Aluminium
Gehäusebeschichtung: pulverbeschichtet
Abdeckung: opal
Nettogewicht: 1185 g
Garantie: 5 Jahre
Mittlere Lebensdauer (L80/B20): 50000 h
