Alvera Line MKII 1500 60-840-8400LM DALI Dim
Order number: LG30461DA
Prices are only visible after login.
Availability: on request
Dimensions
- Order number: : LG30461DA
- Luminous Flux: 8400 lm
- Power Draw: 60 W
- Light Color: neutralwhite (4000 K)
- Input Current: AC 180-264 max.V, 50Hz
- Color Rendering Index (CRI): ≥80 Ra
- IP Code: 65
- Beam Angle: 120°
- LED-Chip: Epistar SMD 2835
- Housing Color: white
- Dimensions: 1525x85x78 mm
- Warranty: 5 years
LED Tri-proof light with Dali Dimming The Litegear® Alvera is a stylish,... more
Product information "Alvera Line MKII 1500 60-840-8400LM DALI Dim"
LED Tri-proof light with Dali Dimming
The Litegear® Alvera is a stylish, waterproof LED fixture with IP65 standard and high mechanical protection. Alvera Line LED is equipped with LED boards with very high system efficency up to 145 Lumen/Watt and available in different lengths and in different power classes.
Based on a strong aluminum profile with excellent heat dissipation for long lifespan of up to 50.000 hours and a opal PC diffuser Litegear® created a unique LED weatherproof luminaire with easy and fast installation and daisy chain function trough easy access endcaps and junction terminal. Alvera has a fast cash back due to its excellent performance and high efficency up to 7500 Lumen. Alvera is the perfect luminaire for industrial applications in factories, warehouse, coolhouse storage, parking lots, sellers or just outside. Up to 5 years full warranty (or max. 25000 hours of use)! Alvera comes with a high quality LED driver! Dali dimmable version.
Related links to "Alvera Line MKII 1500 60-840-8400LM DALI Dim"
Technical Details:
| Luminous Flux: | 8400 lm |
| LED Output: | 58 W |
| Light Yield: | 140 lm/W |
| Light Temperature: | 4000 K |
| Light Color: | neutralwhite |
| Color Rendering Index: | ≥80 Ra |
| Color Consistency (SDCM): | <4 |
| Beam Angle: | 120 ° |
| Light Emission: | downward |
| Dimmable: |  |
| Method of Dimming: | DALI |
| LED-Chip Manufacturer: | Epistar |
| LED-Chip: | SMD 2835 |
| Number of LED: | 325 |
| Ignition Time: | <0,5 s |
| Glow Wire Test 650°C/30s | |
| Input Current: | AC 180-264 max.V, 50Hz |
| Power Consumption: | 60 W |
| Contains Driver: | |
| Driver Manufacturer: | Boke |
| Power Factor (PF): | >0.95 |
| Input Driver: | terminal |
| Output of Driver: | DC 27-40V, 1400mA |
| CC/CV: | CC |
| Input Lamp: | Terminal |
| Switching Cycles: | >50.000 |
| Electrical Protection Class: | I |
| Ambient Temperature (TA): | -20°C - 60°C |
| Storage Temperature: | -40°C - 55°C |
| Dimensions: | 1525x85x78 mm |
| Mounting: | ceiling,wall |
| Montageart: | surface mounted |
| IP Class: | 65 |
| IK Code: | 10 |
| Housing Color | white |
| Housing Material: | aluminum |
| Special Feature of Housing: | opt. Polycarbonat Cover |
| Cover: | opal |
| Net Weight: | 2600 g |
| Type of Packaging: | box |
| Dimensions of Packaging: | 160x92x82 |
| Weight incl. Packaging: | 2.88 kg |
| Content Master Package: | 4 |
| Dimensions of Master Package: | 1620x190x220 mm |
| Weight Master Package: | 14 kg |
| Product Line: | Premio Line |
| Warranty | 5 years |
| Operating Hours: | >50.000 h L80/B10 |
| Disposal Obligation: | |
| Customs Tariff Number: | 9405499090 |
| Certifications | CE,LM80,D |
| Barcode: | 4250557821283 |
| Einfache, und schnelle Montage, In/Out Terminal | |
| Schnellverschluß Endkappen | |
| Dali dimmbar, Durchgangsverdrahtung | |
| 5 wire Terminal for loop, Dali dim | |
LED-Feuchtraumwannenleuchte in modernem Design mit einer schlagfesten PC-Abdeckung IK10 und... more
LED-Feuchtraumwannenleuchte in modernem Design mit einer schlagfesten PC-Abdeckung IK10 und optionaler Sensorik
Vorschaltgerät: LED-Treiber
Dimmfähig: ja
Temperaturbereich: -20°C - 60°C
Lichtstrom: 8400 lm
LED-Leistung: 60 W
Leuchten-Lichtausbeute: 140 lm/W
Farbtemperatur: 4000 K
Lichtfarbe: neutralwhite
Farbwiedergabeindex (Ra): >80
Farbtoleranz (SDCM): <4
Abstrahlwinkel: 120°
Lichtaustritt: direkt
Maße: 1525x85x78 mm
Montageart: Aufbau (Decke,Wand)
Schutzklasse (DIN EN 61140): I
Schutzart (DIN EN 60529): IP65
Stoßfestigkeitsgrad (IEC 62262): IK10
Außenfarbe: white
Gehäusematerial: Aluminium
Abdeckung: opal
Nettogewicht: 2600 g
Garantie: 5 Jahre
Mittlere Lebensdauer (L80/B10): 50000 h
Vorschaltgerät: LED-Treiber
Dimmfähig: ja
Temperaturbereich: -20°C - 60°C
Lichtstrom: 8400 lm
LED-Leistung: 60 W
Leuchten-Lichtausbeute: 140 lm/W
Farbtemperatur: 4000 K
Lichtfarbe: neutralwhite
Farbwiedergabeindex (Ra): >80
Farbtoleranz (SDCM): <4
Abstrahlwinkel: 120°
Lichtaustritt: direkt
Maße: 1525x85x78 mm
Montageart: Aufbau (Decke,Wand)
Schutzklasse (DIN EN 61140): I
Schutzart (DIN EN 60529): IP65
Stoßfestigkeitsgrad (IEC 62262): IK10
Außenfarbe: white
Gehäusematerial: Aluminium
Abdeckung: opal
Nettogewicht: 2600 g
Garantie: 5 Jahre
Mittlere Lebensdauer (L80/B10): 50000 h
