Plug and Play Emergency Kit für Retrova Extrem 3W/3h
Order number: LG30804
Available soon
Prices are only visible after login.
Availability: on request
Dimensions
- Order number: : LG30804
- Luminous Flux: 540 lm
- Power Draw: 3 W
- Input Current: AC 220-240V, 50/60Hz
- IP Code: 20
- Housing Color: white
- Dimensions: 235x65x42 mm
- Warranty: 2 years
Battery emergency Pack for Ekova Select and Retrova Extreme ... more
Product information "Plug and Play Emergency Kit für Retrova Extrem 3W/3h"
- Battery emergency Pack for Ekova Select and Retrova Extreme
- Battery emergency driver incl. battries LiFePo4, replaceable
- Plug and Play accessory kit, no tools needed
- Can be installed easily even afterwards by a technician
- Battery capacity: 3 hours
- Feed in over separate permanent L 220-240V AC
- System efficiency 160-180lm/W x 3W = 480-540lm
- automatic selftest: weekly shorttest and annual long duration test
Related links to "Plug and Play Emergency Kit für Retrova Extrem 3W/3h"
Technical Details:
| Luminous Flux: | 540 lm |
| Light Yield: | 180 lm/W |
| Ignition Time: | <1 s |
| Glow Wire Test 650°C/30s |  |
| Input Current: | AC 220-240V, 50/60Hz |
| Power Consumption: | 3 W |
| Driver Manufacturer: | Cyantronic |
| Input Driver: | cable with plug |
| Output of Driver: | DC 30-300V, 8-80mA |
| CC/CV: | CV |
| Ambient Temperature (TA): | 0°C - 50°C |
| Storage Temperature: | -40°C - 60°C |
| Dimensions: | 235x65x42 mm |
| Mounting: | ceiling,wall |
| Montageart: | recessed |
| IP Class: | 20 |
| Housing Color | white |
| Housing Material: | Blech-plastic |
| Special Feature of Housing: | steckbares System |
| Net Weight: | 233 g |
| Luminaire Type: | Fluchtwegleuchtung |
| Testing Facility: | automatischer Selbsttest |
| Forward Voltage Range: | 144-187 |
| Battery Warranty: | 2 |
| Discharge Duration: | ≥3 h |
| Battery Type: | LiFePo4 |
| Battery Current: | 2000 mA |
| Battery Charge Duration: | 12 h |
| Initial Charge Duration: | 24 h |
| Charging Power Consumption: | 3.5 W |
| Battery Cell Quantity | 2 |
| Luminous Flux in Battery Mode: | 480 lm |
| Standards for emergency luminaires: | DIN EN 60598-2-22, DIN EN 62034: 2012 |
| Type of Packaging: | box |
| Weight incl. Packaging: | 0.264 kg |
| Content Master Package: | 50 |
| Dimensions of Master Package: | 420x330x356 mm |
| Weight Master Package: | 14 kg |
| Product Line: | Advance Line |
| Warranty | 2 years |
| Disposal Obligation: | |
| Customs Tariff Number: | 9405119090 |
| Certifications | CE |
| Incll. LiFePo4 Battery 1800/3600mAh 3,2-3,6V 250mA | |
| EN: 60598-2-22, EN61347-1, EN61347-1 und -2-7 | |
| Emergency Time: 1,5-3h | |
| Charging time: 24h | |
| 3W Battery Emergency Power / 540lm masx, | |
