Luna Plane IP66 Floodlight 120-840-16000LM

LG10962A
Prices are only visible after login.

Availability: on request

Dimensions

Dimensions
  • LG10962A
  • Luminous Flux: 16000 lm
  • Power Draw: 120 W
  • Light Color: neutralwhite (4000 K)
  • Color Rendering Index (CRI): ≥80 Ra
  • IP Code: 66
  • Beam Angle: 120°
  • LED-Chip: Cree SMD 2835
  • Housing Color: black
  • Dimensions: 400x340x90 mm
  • Warranty: 3 years

Luminous Flux

16000
lm

Power Draw

120 W

Light Color

4000 K
neutralwhite

Color Rendering Index (CRI)

CRI
>80 Ra

IP Code

IP 66

Beam Angle

120°

ceiling, wall

mounting type

Dimensions

(LxBxH) in mm
400x340x90

Warranty

3 years

The light source may only be replaced by qualified persons

The driver may only be replaced by qualified persons

LED Flood Light   Litegear® Luna Plane is a flat and stylish LED outdoor... more
Product information "Luna Plane IP66 Floodlight 120-840-16000LM"
LED Flood Light

Litegear® Luna Plane is a flat and stylish LED outdoor floodlight. Due to the use of alluminum dicast housing, inox screws and alu bracket it has a excellent corrosion resistance. Much better than standard flood lights with steel brackets. Luna Plane is the perfect solution for use in factories, mobile for construction work, garden, parking area or for architectural applications. You can use it permanently outside in rough environment conditions. We use very efficient LED chips with a high lightoutput. The LED chips have a optimized heat dissipation to guarantee a long lifespan. Compared to other outdoor devices we have a much better Color rendering Index which let colors shine more naturally. After switching on the luminaire you have a instant full light without infrared waves which allows you to use it more closely to heat sensitive materials and makes working in front of the flood light more confenient and less sweatty. The internal power supply is power factor corrected for less waste of electricity.
Related links to "Luna Plane IP66 Floodlight 120-840-16000LM"
Technical Details:

Luminous Flux: 16000 lm
LED Output: 120 W
Light Yield: 133 lm/W
Light Temperature: 4000 K
Light Color: neutralwhite
Color Rendering Index: ≥80 Ra
Color Consistency (SDCM): <4
Beam Angle: 120 °
Light Emission: sideward
LED-Chip Manufacturer: Cree
LED-Chip: SMD 2835
Ignition Time: <0,5 s
Power Consumption: 120 W
Contains Driver: ja
Driver Manufacturer: Meanwell
Power Factor (PF): >0.95
Input Driver: cable with plug
Output of Driver: DC 30 - 46V, 2000mA
CC/CV: CC
Input Lamp: cable with plug
Switching Cycles: >50.000
Electrical Protection Class: II
Compatible with Emergency Current: ja
Ambient Temperature (TA): -20°C - 50°C
Dimensions: 400x340x90 mm
Mounting: ceiling,wall
Montageart: surface mounted
IP Class: 66
IK Code: 08
Housing Color black
Housing Material: aluminum
Coating: powder-coated
Cover: prismatic
Net Weight: 7300 g
Type of Packaging: box
Dimensions of Packaging: 485x415x135
Weight incl. Packaging: 8.01 kg
Content Master Package: 2
Dimensions of Master Package: 415x285x510 mm
Weight Master Package: 19 kg
Product Line: Advance Line
Warranty 3 years
Operating Hours: >50.000 h L80/B20
Disposal Obligation: ja
Customs Tariff Number: 9405499090
Certifications CE,GS,ENEC,LM80,D
Barcode: 4250557812212
Meanwell Driver
LED-Outdoorstrahler aus hochwertigem Aluminium-Spritzguss-Gehäuse mit Alu-Montagebügel, IP66 more
LED-Outdoorstrahler aus hochwertigem Aluminium-Spritzguss-Gehäuse mit Alu-Montagebügel, IP66
Vorschaltgerät: LED-Treiber
Temperaturbereich: -20°C - 50°C
Lichtstrom: 16000 lm
LED-Leistung: 120 W
Leuchten-Lichtausbeute: 133 lm/W
Farbtemperatur: 4000 K
Lichtfarbe: neutralwhite
Farbwiedergabeindex (Ra): >80
Farbtoleranz (SDCM): <4
Abstrahlwinkel: 120°
Lichtaustritt: direkt
Maße: 400x340x90 mm
Montageart: Aufbau (Decke,Wand)
Schutzart (DIN EN 60529): IP66
Stoßfestigkeitsgrad (IEC 62262): IK08
Außenfarbe: black
Gehäusematerial: Aluminium
Gehäusebeschichtung: pulverbeschichtet
Abdeckung: prismatisch
Nettogewicht: 7300 g
Garantie: 3 Jahre
Mittlere Lebensdauer (L80/B20): 50000 h
